Design of a Fingerprint Recognition System Based on Microcontroller
Liao, Siyuan (2023)
2023
All rights reserved. This publication is copyrighted. You may download, display and print it for Your own personal use. Commercial use is prohibited.
Julkaisun pysyvä osoite on
https://urn.fi/URN:NBN:fi:amk-2023052915305
https://urn.fi/URN:NBN:fi:amk-2023052915305
Tiivistelmä
It describes the development and deployment of a microcontroller-based fingerprint recognition system. The system employs biometric technology to recognize fingerprints, which is known for its ease of use, precision, and affordability.
The system includes a fingerprint module and a microcontroller, performing fingerprint image collection, processing, feature extraction, comparison, and matching of feature values. The resulting output is displayed on a 12864 LCD module, and external devices are controlled using a relay module. The microcontroller used in the project is the STC89C52RC, and the fingerprint module used is the ZFM-60. The system also implemented a 4 x 4 matrix key, which perform the functions of password entering and menu selection. A 24C02 EEPROM is used in the project to store the passwords given by the user.
The system was tested using a database of fingerprints, and the results showed that it achieved a high accuracy rate. The proposed system can be used in various applications, such as security systems, access control systems, and attendance systems. It offers low-cost, efficient, and reliable biometric authentication, and can contribute to the development of biometric systems for different applications.
